| Product | SIM7500A-PCIE | SIM7500AD-PCIE | SIM7500V-PCIE | SIM7500SA-PCIE | SIM7500E-PCIE | SIM7500JC-PCIE | SIM7500JE-PCIE | ||
| Form Factor | Mini PCIE | Mini PCIE | Mini PCIE | Mini PCIE | Mini PCIE | Mini PCIE | Mini PCIE | ||
| Dimensions(mm) | 50.8*30*5.35 | 50.8*30*5.35 | 50.8*30*5.35 | 50.8*30*5.35 | 50.8*30*5.35 | 50.8*30*5.35 | 50.8*30*5.35 | ||
| Frequency Bands | LTE-FDD | B2/B4/B12 | B2/B4/B12 | B4/B13 | B1/B3/B5/B7/B8/B28 | B1/B3/B7/B8/B20 | B1/B18/B19/B26 | B1/B3/B8 | |
| WCDMA | B2/B5 | B2/B5 | B1/B5 | B1/B8 | |||||
| 900/1800MHz | |||||||||
Temperature GNSS | -40℃ ~ +85℃ Optional | -40℃ ~ +85℃ Optional | -40℃ ~ +85℃ Optional | -40℃ ~ +85℃ Optional | -40℃ ~ +85℃ Optional | -40℃ ~ +85℃ Optional | -40℃ ~ +85℃ Optional | ||
| Electrical Features | |||||||||
| Supply Voltage(V) | 3.0~ 3.6 | 3.0~ 3.6 | 3.0~ 3.6 | 3.0~ 3.6 | 3.4~ 4.2 | 3.4~ 4.2 | 3.4~ 4.2 | ||
| Power Consumption(mA) | LTE | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | |
| WCDMA,DRX=9 | 3.3 | 3.3 | 3.3 | 3.3 | 3.3 | ||||
GSM, BS_PA_ | 2.8 | ||||||||
| Data Transfer | |||||||||
| LTE(Mbps) | 10(DL)/5(UL) | 10(DL)/5(UL) | 10(DL)/5(UL) | 10(DL)/5(UL) | 10(DL)/5(UL) | 10(DL)/5(UL) | 10(DL)/5(UL) | ||
| HSPA+(Mbps) | 42(DL)/5.76(UL) | 42(DL)/5.76(UL) | 42(DL)/5.76(UL) | 42(DL)/5.76(UL) | |||||
| WCDMA(Kbps) | 384(DL)/384(UL) | 384(DL)/384(UL) | 384(DL)/384(UL) | 384(DL)/384(UL) | |||||
| GPRS/EDGE(Kbps) | 236.8(DL)/236.8(UL) | ||||||||
| Software Features | |||||||||
| Protocol | TCP/IP/IPV4/IPV6/ Multi-PDP/ /HTTPS/DNS | TCP/IP/IPV4/IPV6/ Multi-PDP/ /HTTPS/DNS | TCP/IP/IPV4/IPV6/ Multi-PDP/ /HTTP/HTTPS/DNS | TCP/IP/IPV4/IPV6/ Multi-PDP/ /HTTP/ HTTPS/DNS | TCP/IP/IPV4/IPV6/ Multi-PDP/ /HTTP/ HTTPS/DNS | TCP/IP/IPV4/IPV6/ Multi-PDP/ /HTTP/HTTPS/DNS | TCP/IP/IPV4/IPV6/ Multi-PDP/ /HTTPS/DNS | ||
| TLS | ● | ● | ● | ● | ● | ● | ● | ||
| File System | ● | ● | ● | ● | ● | ● | ● | ||
| Audio Record/Play | o | o | o | o | o | o | |||
| TTS | o | o | o | o | o | o | |||
| DTMF | o | o | o | o | o | o | |||
| LBS | ● | ● | ● | ● | ● | ● | ● | ||
| FOTA | ● | ● | ● | ● | ● | ● | ● | ||
| Jamming Detection | ● | ● | ● | ● | ● | ● | ● | ||
| Android RIL | Android 5.0/6.0/ | Android 5.0/6.0/ 7.0/8.0/9.0 | Android 5.0/6.0/ 7.0/8.0/9.0 | Android 5.0/6.0/ 7.0/8.0/9.0 | Android 5.0/6.0/ 7.0/8.0/9.0 | Android 5.0/6.0/ 7.0/8.0/9.0 | Android 5.0/6.0/ 7.0/8.0/9.0 | ||
| USB Driver | Microsoft Windows 7/8/10Linux/ Android | Microsoft Windows 7/8/10Linux /Android | Microsoft Windows 7/8/10Linux/ Android | Microsoft Windows 7/8/10Linux/ Android | Microsoft Windows 7/8/10Linux/ Android | Microsoft Windows 7/8/10Linux/ Android | Microsoft Windows 7/8/10Linux/ Android | ||
| WWAN (RNDIS) | ● | ● | ● | ● | ● | ● | ● | ||
| ECM | ● | ● | ● | ● | ● | ● | ● | ||
| MBIM | Win8/Win10 | Win8/Win10 | Win8/Win10 | Win8/Win10 | Win8/Win10 | Win8/Win10 | Win8/Win10 | ||
| NDIS | Linux/Windows 7/8/10 | Linux/Windows 7/8/10 | Linux/Windows 7/8/10 | Linux/Windows 7/8/10 | Linux/Windows 7/8/10 | Linux/Windows 7/8/10 | Linux/Windows 7/8/10 | ||
| Firmware Upgrade | USB/FOTA | USB/FOTA | USB/FOTA | USB | USB/FOTA | USB/FOTA | USB/FOTA | ||
| Interfaces | |||||||||
| SIM Card | 1.8V/3.0V | 1.8V/3.0V | 1.8V/3.0V | 1.8V/3.0V | 1.8V/3.0V | 1.8V/3.0V | 1.8V/3.0V | ||
| UART | ● | ● | ● | ● | ● | ● | ● | ||
| USB | ● | ● | ● | ● | ● | ● | ● | ||
| PCM | o | o | o | o | o | o | |||
| Analog Audio | o | o | o | o | o | o | |||
| Embedded SIM card socket | o | o | o | o | o | o | o | ||
| I2C | ● | ● | ● | ● | ● | ● | ● | ||
| Diversity Receiver | ● | ● | ● | ● | ● | ● | ● | ||
| Certification | |||||||||
| Regulatory | FCCICPTCRBRoHSREACHAT&TRogers | FCCPTCRBRoHSREACHT-Mobile | FCCGCFRoHSREACHVerizon | CE-REDACMANCCRoHS REACHDeutsche Telekom | CE-REDACMANCCRoHS REACH | TelecJATERoHSREACH | TelecJATERoHSREACHSoftbank | ||
| Carrier | AT&T/Rogers | T-Mobile | Verizon | Deutsche Telekom | Softbank | ||||
